New 2027 Ford E-Stripped Chassis E-450 DRW
- VIN: 1FC4E4KN9VDD09873
- Stock: VDD09873
New 2027 Ford E-Stripped Chassis E-450 DRW
VIN: 1FC4E4KN9VDD09873STOCK: VDD09873
Basic Info
-
Exterior:White
-
Drivetrain:4x2
-
Interior:Seats Not Included
-
Transmission:6-Speed O/D w/Tow Haul transmission
-
Engine:7.3L V8 Premium-Rated Engine
Description
Vehicle Details
Exterior
- Wheels: 16" x 6" White Painted Steel
- Variable Intermittent Wipers
Interior
- Seats Not Included (No Pedestal) -inc: throw away driver seat
- Fixed Driver Seat
- Fixed Passenger Seat
- Manual Tilt/Telescoping Steering Column
- Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure and Engine Coolant Temp
- Urethane Gear Shifter Material
- Tracker System
- Power Door Locks
- Driver Information Center
- Analog Appearance
Entertainment
- Radio Delete
Mechanical
- Engine: 7.3L V8 Port Fuel Injected Gasoline
- 4.56 Axle Ratio
- GVWR: 14,500 lb Payload Package
- 50 State Emission System
- Transmission w/Driver Selectable Mode
- Rear-Wheel Drive
- 78-Amp/Hr 750CCA Maintenance-Free Battery
- HD 210 Amp Alternator
- HD Gas-Pressurized Shock Absorbers
- Front And Rear Anti-Roll Bars
- Hydraulic Power-Assist Steering
- Single Stainless Steel Exhaust
- 55 Gal. Fuel Tank
- Dual Rear Wheels
- Front Suspension w/Coil Springs
- Solid Axle Rear Suspension w/Leaf Springs
- 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs and Hill Hold Control
Tech Specs
- Vehicle Name: Ford E-Series Stripped Chassis
- Body Style: Chassis
- Body Code: H
- Drivetrain: Rear Wheel Drive
- Passenger Capacity: 1
- Base Curb Weight: 4805
- Gross Axle Wt Rating - Front: 5000
- Gross Axle Wt Rating - Rear: 9600
- Curb Weight - Front: 2531
- Curb Weight - Rear: 2274
- Gross Vehicle Weight Rating Cap: 14500
- Gross Combined Wt Rating: 22000
- Dead Weight Hitch - Max Trailer Wt.: 5000
- Dead Weight Hitch - Max Tongue Wt.: 500
- Wt Distributing Hitch - Max Trailer Wt.: 7500
- Wt Distributing Hitch - Max Tongue Wt.: 750
- Maximum Trailering Capacity: 7500
- Engine Order Code: 99N
- Engine Type: Regular Unleaded V-8
- Displacement: 7.3 L/445
- Fuel System: Sequential MPI
- SAE Net Horsepower @ RPM: 325 @ 3750
- SAE Net Torque @ RPM: 450 @ 3750
- Trans Order Code: 44P
- Trans Type: 6
- Trans Description Cont.: Automatic w/OD
- Trans Description Cont. Again:
- First Gear Ratio (:1): 3.97
- Second Gear Ratio (:1): 2.32
- Third Gear Ratio (:1): 1.52
- Fourth Gear Ratio (:1): 1.15
- Fifth Gear Ratio (:1): 0.86
- Sixth Gear Ratio (:1): 0.67
- Reverse Ratio (:1): 3.13
- Trans PTO Access: No
- Transfer Case Model: None
- Transfer Case Power Take Off: No
- Cold Cranking Amps @ 0° F (Primary): 750
- Cold Cranking Amps @ 0° F (2nd): 750
- Maximum Alternator Capacity (amps): 210
- Engine Oil Cooler: None
- Suspension Type - Front: Other
- Suspension Type - Rear: Leaf
- Spring Capacity - Front: 5000
- Spring Capacity - Rear: 9600
- Axle Type - Front: Independent
- Axle Type - Rear: Rigid Axle
- Axle Capacity - Front: 5000
- Axle Capacity - Rear: 9600
- Axle Ratio (:1) - Front: 4.56
- Axle Ratio (:1) - Rear: 4.56
- Front Tire Order Code: T68
- Rear Tire Order Code: T68
- Spare Tire Order Code:
- Front Tire Size: LT225/75SR16
- Rear Tire Size: LT225/75SR16
- Spare Tire Size:
- Front Tire Capacity: 5000
- Rear Tire Capacity: 9880
- Revolutions/Mile @ 45 mph - Front: 709
- Revolutions/Mile @ 45 mph - Rear: 709
- Front Wheel Size: 16 X 6
- Rear Wheel Size: 16 X 6
- Spare Wheel Size:
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material:
- Steering Type: Re-Circulating Ball
- Turning Diameter - Curb to Curb: 54.8
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line): 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 13.6
- Rear Brake Rotor Diam x Thickness: 13.6
- Drum - Rear (Yes or ):
- Rear Drum Diam x Width:
- Fuel Tank Capacity, Approx: 55
- Wheelbase: 158
- Length, Overall: 252.7
- Overhang, Rear w/o bumper: 68.5
- Country of Origin: United States Ford Truck Stripped Chassis Us
Details
- GVWR: 14,500 Lb Payload Package
- Order Code 790A
- Dual rear wheels
- Embedded Modem Delete
- Seats Not Included (no Pedestal)
- Telescoping steering wheel
- Tilt steering wheel
- Voltmeter
- Power steering
- 4-Wheel Disc Brakes
- Front anti-roll bar
- Front wheel independent suspension
- ABS brakes
- Rear anti-roll bar
- Traction control
- 16" x 6" White Painted Steel Wheels
- Cruise Control
- Variably intermittent wipers
- Electronic Stability Control
- 4.56 Axle Ratio
- ABS
- Rear Wheel Drive
- Dual Rear Wheels
- 8 Cylinder Engine
- Gasoline Fuel
- Daytime Running Lights
- Power Steering
- Adjustable Steering Wheel
- Tires - Front All-Season
- Tires - Rear All-Season
- Traction Control
- 6-Speed A/T
- Intermittent Wipers
- A/T
- Variable Speed Intermittent Wipers
- Steel Wheels
